ChatillonMT500力學測試機
ChatillonMT500力學測試機Chatillon®MT500係列機械試驗台測力應用到500磅(2.5千牛)是一個易於使用的解決方案的能力。這個試驗台可配備快速行動杠杆或精密控製十字頭速度和行程手輪。mt500試驗台可台安裝的,安裝的,牆壁安裝或水平安裝。垂直間隙可從750毫米(29.5英寸)高達1500毫米(60英寸)。
ChatillonMT500力學測試機的詳細資料
ChatillonMT500力學測試機
The CHATILLON®MT500 Series mechanical test stand is an easy-to-use solution for force measurement applications up to 500 lbf (2.5kN) capacities. The test stand may be equipped with a quick-action lever or precision handwheel for controlling crosshead speed and travel. The MT500 test stand can be bench mounted， wall mounted or positioned horizontally. Vertical clearances are available from 750mm (29.5 inch) up to 1500mm ( 60 inch). Standard stroke is 6 inches (150mm)， although longer strokes can be accommodated as a special order.ChatillonMT500力學測試機
The MT500 Series features an innovative design that maximizes working space and simplifies operation and maintenance. The single column design with 150mm (6 in) throat is ideal for large specimens. The removable platen is designed to accommodate metric and imperial threaded fixtures. Special gauge adapter make gauge alignment automatic. Options include a digital travel indicator， capable of displaying travel up to 0.01mm (0.0005 inch) and column ruler which is graduated in millimeters and inches.
The MT500 Series includes hook， compression plate， adapters and gauge mounting hardware.
