美國Chatillon LG-050機械測力計的詳細資料

美國Chatillon LG-050機械測力計

LG 係列是一套出色而經濟的解決方案，於拉伸或壓縮測試。這些機械測力計具有 2.25 英寸刻度盤，甚至在上限極限負載時，依然可以輕易地手動安裝靈活堅固的夾具。

拉斷線纜和軟管，並記錄必要的上限拉力。可用於開關測試或者安裝在測試支架上檢測激活刹車所必須的壓力。

LG 係列主要特色：美國Chatillon LG-050機械測力計
- 三種分度單位(磅力、千克力和牛)
- 真正安全
- 峰值開關

LG Series Mechanical Force Gauge

The CHATILLON® LG Series mechanical force gauge is ideal for a wide range of force testing applications. Based on our popular DPP Series force gauge， the LG Series features a larger， 2.25-inch dial for improved resolution and readability， peak hold button， ergonomic shape and improved accuracy of +0.5% of full scale. The LG gauge is an excellent， economical solution for tensile or compression testing.
The durable， plastic housing fits naturally in the hand for a comfortable and firm grip even at maximum loads. Gauges may be mounted to a test stand for even greater control and consistent results in repetitive testing applications. Easy to read concentric dial measures clockwise only. Dial rotates 360-degrees for taring. A peak hold button captures peak readings and can be easily and quickly returned to zero. A mechanical overload feature protects the gauge from damage. Available in lbf， kgf or N units of measure. LG Series gauges come complete with protective carrying case and a set of stainless steel attachments.
A Certificate of Calibration with Data is supplied standard.

Features 美國Chatillon LG-050機械測力計
n Three Graduation Styles
 - LBF
 - KGF
 - Newtons
n Tensile (Pull) and Compression (Push) Testing
n Peak Load Switch
n Tare Ring
n Intrinsically Safe
n NIST Calibration with Data
n 2 Year Warranty

Specifications
Accuracy： +0.5% of Full Scale
Overload Capacity： 110% of Rated Capacity
Maximum Overload： 150% of Rated Capacity
Tare Capacity： 10% of Rated Capacity
Dial Resolution： 0.5% of Full Scale
Deflection (Full Scale)： 10mm (.394 inches)
Operating Temperature： 40°F to 110°F
 5°C to 45°C
Instrument Weight： 1.5 lbs (0.68 kg)
Shipping Weight： 8.4 lbs (3.80 kg)
